Vol. 7, No 1: 61–67.

Materials technology

 2022

Scientific article

UDK 621.86/.87; 621.791.052.7
pdf-version

Maksim Sulkonen
bachelor, Petrozavodsk State University
(Petrozavodsk, Russian Federation),
maks.sulkonen@list.ru

Calculation of the welded seam of the lifting device

Scientific adviser:
Andrey A. Shubin
Paper submitted on: 03/29/2022;
Accepted on: 03/29/2022;
Published online on: 04/05/2022.
 Abstract. The article deals with the issues of calculation and design of welded metal structures in mechanical engineering. An example of the design of a lifting device is given and strength calculations are carried out using the method of resistance of materials and the finite element method using domestic software. Conclusions are drawn about the performance of the design.
Keywords: calculation of welds, lifting device, lifting beam, calculation by the finite element method

For citation: Sulkonen, M. Calculation of the welded seam of the lifting device. StudArctic forum. 2022, 7 (1): 61–67.

References

Vaison A. A. Crane lifting devices : handbook. Moscow: Mashinostroenie, 2005. 304 p.

Kislenkov V. V. Equipment of thermal workshops: textbook. St. Petersburg: SPbGPU, 2011.142 p.

Calculation of welded joints - formulas, parameters and examples : [Electronic resource]. Access mode: https://nauka.club/materialovedenie/raschet-svarnykh-soedineniy.html — (accessed: 12.05.2021).

Manufacture of traverse hook suspensions : [Electronic resource]. Access mode: http://www.kranmash.su/Entsiklopediya-proizvodstva-podemnich-kranov/Izgotovlenie-travers-kriukovich-podvesok.html. (accessed: 12.05.2021).

APM FEM strength analysis system for COMPASS-3D. Version 18.0. Access mode: https://apm.ru/apm-fem . (accessed: 13.12.2021).
